微波吸收材料用于控制600MHz-75GHz范围内的干扰和电磁能量。有空腔谐振和表面电流抑制吸收材料；有适用于宽频和调谐应用的自由空间吸收材料;
有适用于端接负载的高损耗可加工磁棒、磁条和磁片；并提供定制裁切配置和精密成型解决方案。 |
爱默生·康明微波产品公司是一家“微波吸收材料” 领域全球领先的著名企业,
拥有 50 多年的辉煌历史, 在比利时的韦斯达路 (Westerlo) 和美国马萨诸塞州的 Randolph 设有两家总面积超过
151,000 平方英尺生产厂,
具有广泛的生产能力，能够按客户要求的配置提供冲切、机械加工和喷水切割的部件，拥有采用最新的自动化“就地铸模”(MIP)
工艺、注塑成型, 自动化产碳技术，每周可以生产 10,000 平方英尺以上的浸碳和喷碳泡沫塑料产品。
该公司已成为面向无线通讯,消费电子,生物医学,汽车和军用市场的吸收,屏蔽及特种电介质材料领域唯一通过 ISO9001
认证的厂商, 生产ECCOSORB®、ECCOSHIELD® 和 ECCOSTOCK®
产品是当今市场上的行业标准。 |
|
 |
| |
 |
Product Index
Absorbers
|
Description |
Frequency
|
|
|
|
|
Narrow Band Free
Space Absorbers |
|
ECCOSORB®
SF |
Resonant, magnetically-loaded,
electrically non-conductive
silicone sheet with good high
power performance |
1
to 18 GHz
|
|
ECCOSORB®
SFU |
Urethane version of the ECCOSORB®
SF series |
1
to 18 GHz |
ECCOSORB® DSF
|
Resonant, dielectrically-loaded,
electrically non-conductive,
corrosion resistant, silicone
sheet
|
3
to 17 GHz |
|
|
|
|
|
Broad Band Free Space
Absorbers |
ECCOSORB® FGM
|
Flexible, magnetically-loaded,
electrically non-conductive
silicone sheet |
2
to 12 GHz |
ECCOSORB® FGMU
|
Urethane version of the ECCOSORB®
FGM series |
2
to 12 GHz |
ECCOSORB® AN
|
Multi-layered,
carbon-impregnated polyurethane
foam sheets |
0.6 to 40 GHz |
ECCOSORB® ANW
|
Weatherproof version of the
ECCOSORB® AN series |
0.6 to 40 GHz |
ECCOSORB® HR
|
Open-cell, carbon-impregnated,
polyurethane foam sheet with
controlled conductivity gradient
|
5
to 70 GHz |
|
|
|
|
Cavity Resonance
Absorbers
|
ECCOSORB® GDS
|
Thin, flexible,
magnetically-loaded,
electrically non-conductive
silicone sheet that is fire
retardant per the UL-94 V1
standard |
6
to 35 GHz |
|
ECCOSORB®
GDSU |
Urethane version of the ECCOSORB®
GDS series |
6
to 35 GHz |
ECCOSORB® FDS
|
Thin, flexible, ferrite-loaded,
electrically non-conductive
silicone sheet |
0.8 to 18 GHz |
|
ECCOSORB®
MCS |
Thin, flexible,
magnetically-loaded,
electrically non-conductive
silicone sheet that is fire
retardant per the UL-94 V1
standard |
0.8 to 18 GHz |
ECCOSORB® MCSU
|
Urethane version of the ECCOSORB®
MCS series |
0.8 to 18 GHz |
ECCOSORB® VF-30
|
Thin, resistive vinyl plastic
sheet |
1
to 18 GHz |
ECCOSORB® LS
|
High-loss, flexible,
carbon-impregnated urethane foam
sheets |
1
to 26 GHz |
ECCOSORB® QR-13AF
|
High-loss, flexible,
carbon-impregnated urethane foam
sheet that is fire retardant per
the UL-94-HF-1 standard
|
1
to 26 GHz |
ECCOSORB® BSR
|
Ultra-thin, high-loss, flexible,
magnetically-loaded,
electrically non-conductive
silicone sheet |
6
GHz to mm |
ECCOSORB® COATING 300
|
Two-part, iron loaded, lossy
polyurethane coating |
1
to 18 GHz |
|
|
|
|
|
Load Absorbers |
|
ECCOSORB®
MF |
Rigid, magnetically-loaded,
electrically non-conductive
epoxy |
1
to 18 GHz |
|
ECCOSORB®
MF-UHF |
Identical to ECCOSORB®
MF, but for use in the upper UHF
band |
0.8 to 18 GHz |
|
ECCOSORB®
MF500F |
High temperature version of the
ECCOSORB® MF series |
1
to 18 GHz |
|
ECCOSORB®
MFS |
Flexible version of the ECCOSORB®
MF series |
0.8 to 18 GHz |
ECCOSORB® CR
|
Two-part, castable,
magnetically-loaded epoxy series |
0.8 to 18 GHz |
ECCOSORB® CR500
|
High temperature version of the
ECCOSORB® CR series |
0.8 to 18 GHz |
ECCOSORB® CRS
|
Softer, elastomeric version of
the ECCOSORB® CR
series |
0.8 to 18 GHz |
|
ECCOSORB®
CFS-8480 |
Two-part, castable, flexible,
ferrite-loaded silicone rubber |
0.8 to 18 GHz |
|
Dielectrics |
Description |
Loss Tan |
Dielectric |
|
|
|
|
|
|
Low Loss/Low
Dielectric Foam Products |
ECCOSTOCK® SH
|
Rigid, closed-cell, polyurethane
foam sheet series capable of
withstanding temperatures as
high as 275 °F |
0.001 -
0.005 |
1.04 to 1.25 |
ECCOSTOCK® FPH
|
Two-part, foam-in-place resin
equivalent of ECCOSTOCK®
SH |
0.001 - 0.005 |
1.04 to 1.25 |
ECCOSTOCK® LoK
|
Rigid, light weight,
thermosetting syntactic foam
rod, bar, and sheet stock |
<0.004 |
1.7 |
ECCOSTOCK® PP
|
Flexible, closed cell,
hydrocarbon resin foam sheet |
0.0001 |
1.03 - 1.06 |
ECCOSTOCK® FFP
|
One-part, light weight,
free-flowing syntactic foam
powder with glass microspheres
that cures at elevated
temperatures |
0.005 |
1.25 |
|
|
|
|
|
|
Low Loss/Low
Dielectric Thermoset Materials |
ECCOSTOCK® HT0003
|
Rigid, high temperature,
thermoset rod and sheet stock |
<0.0003 |
2.2 |
ECCOSTOCK® CPE
|
Rigid, thermoset, cross-linked
polyethylene rod and sheet stock |
0.0001 |
2.4 |
ECCOSTOCK® 0005
|
Rigid, thermoset, cross-linked
polystyrene rod and sheet stock |
0.0005 |
2.54 |
|
|
|
|
|
|
Low
Loss Materials with Controlled
Dielectric Constants |
|
ECCOSTOCK® HiK |
Rigid rod, bar, and sheet stock
series with selected dielectric
constants up to 15.
|
<0.002 |
3
to 15
|
|
ECCOSTOCK® HiK500F |
High temperature version of the
ECCOSTOCK® HiK series
with dielectric constants
available up to 30 |
<0.002 |
3
to 30
|
|
|
|
|
|
|
Low Loss Powders,
Resins & Adhesives |
ECCOSTOCK® HiK Powder
|
Reusable, granular, free-flowing
powder series |
0.0004- 0.0007
|
2.5 to 12.0 |
ECCOSTOCK® HiK Cement
|
Two-part, epoxy paste for
bonding ECCOSTOCK®
HiK to itself and other
materials |
0.01 |
3
to 15 |
|
Shielding |
Description |
Resistivity |
| |
|
|
|
Electrically Conductive Caulking
Compounds |
ECCOSHIELD® VY
|
Electrically conductive,
non-hardening silicone based
caulking compound |
0.001 Ω-cm |
|
ECCOSHIELD®
VY-81 |
Electrically conductive,
non-hardening silicone based
caulking compound |
0.01 Ω-cm |
|
ECCOSHIELD®
VX |
Electrically conductive,
non-hardening caulking paste
based on a hydrocarbon resin |
0.05 Ω-cm |
|
|
|
|
|
Electrically
Conductive Sheets |
|
ECCOSHIELD® LSV
|
Highly conductive plastic sheet
based on a vinyl resin and
silver |
0.001 Ω-cm |
ECCOSHIELD® SVR
|
Highly conductive sheet based on
silicone rubber and silver |
0.001 Ω-cm |
|
|
|
|
|
Electrically
Conductive Adhesives and
Coatings |
ECCOSHIELD® ES
|
Highly electrically conductive,
silver based lacquer surface
coating |
<1.0 Ω-cm |
ECCOSHIELD® VCA
|
Highly electrically conductive,
solvent based, adhesive for
ECCOSHIELD® LSV |
<0.001 Ω-cm |
ECCOSHIELD® RVS
|
Highly electrically conductive
adhesive for ECCOSHIELD®
SVR |
<0.002 Ω-cm |
|
ECCOSHIELD®
SO |
Highly electrically conductive,
multi-purpose lubricating grease |
<0.02 Ω-cm |
|
|
|
 |
|
