Electrochemical Oxygen Gas Sensor (SS1118)   Elctrochemical oxygen gas sensor(SS1118) is of a galvanic cell type. SS1118 measure partial pressure of oxygen in air. SS1118 controls oxygen flow with non-porous membrane. SS1118 requires no special preparation or calibration-just plugs it into your interface then it is ready to take readings. SS1118 offers superior performance over the conventional oxygen sensor in the fact that SS118 is not affected by CO2, CO and NOx. SS1118 also show fast response property, high stability and a long life time.         Electrochemical Oxygen Gas Sensor (SS2118)   Electrochemical Oxygen Gas sensor Electrochemical oxygen gas sensor(SS2118) controls oxygen gas flow with micro capillary hole. The output of SS2118 is linearly proportional to the oxygen concentration in the range of 0~30%. SS2118 doesn't measure the partial pressure of oxygen but the volume percent of oxygen in air. The output of SS2118 is very stable under operational temperature range. 　 Operating Condition Sensor Qxygen(SS1118) Qxygen(SS2118) Temperature range -20~50℃ -10~50℃ Relative humidity range 0~99% RH 0~99% RH Pressure range Atmospheric±10% Atmospheric±10% Specifications Detection gas Qxygen(O2) Qxygen(O2) Detection range 0~99% 0~30% Output signal 6±1mV in air 90±20μA in air Response time (T90) ≤ 10 sec ≤ 15 sec Typical baseline range ≤ 0.1% ≤ 0.1% Output linearity linearity linearity Repeatability ± 0.5% ± 0.5% Expected lifetime 2year 2year Physical Characteristics Applications Weigh 6 16g Dimension φ~20.4mm, h~16.6mm φ~20.4mm, h~16.6mm Storage life 3 months 6 months Warranty period 18 months 24 months Applications Combustion effciency analyzer, Food storage, Gas mixer, Medical sensor, Scuba sensor, Dissolved oxygen Ideal for portable instrument, Industry,safety, boiler room etc.     Hydrogen sulfide Sensor (SS1198)   The electrochemical hydrogen sulfide gas sensor(SS1198) measures the concentration of H2S with a spontaneous oxidation-reduction reaction. SS1198 has a high selectivity, good reproducibility, small output drift and no power consumption. SS1198 is very suitable for the gas detectors required in the fields such as petrochemical, mine, waste water plant, etc. 　 Operating condition Sensor Hydrogen sulfide(SS1198) Temperature range -20~50℃ Relative humidity range 15~90% RH Pressure range Atmospheric±10% Performance Detection gas Hydrogen sulfide(H2S) Detection range 0~500ppm Output signal 60±15nA/ppm Response time (T90) ≤ 30 sec Typical baseline range -1 to 1ppm Output linearity linearity Repeatability ± 2% Expected lifetime 2year Physical Characteristics & Applications Weigh 6 Dimension φ~20.4mm, h~16.6mm Storage life 6 months Warranty period 24 months Application field Portable & fixed gas detector, Industrial safety(petrochemical, refining) Waste water, Sewage treatment plant, Mine, etc     Electrochemical Carbon Monoxide Gas Sensor   (SS1128)   The electrochemical carbon monoxide gas sensor(SS1128) has a superior gas selectivity to CO. The output signal of SS1128 is linearly proportion to the CO gas concentration in air. SS1128 is little affected by humidity change. SS1128 also offers superior performance over the conventional semiconductor type in that SS1128 has a high selectivity, good reproducibility, small output drift and no power consumption 　 Operating condition Sensor Carbon monoxide(SS1128) Temperature range -20~50℃ Relative humidity range 15~90% RH Pressure range Atmospheric±10% Performance Detection gas Carbon monoxide(CO) Detection range 0~1,000 ppm Output signal 60±15nA/ppm Response time (T90) ≤ 30 sec Typical baseline range -2 to 3ppm Output linearity linearity Repeatability ± 2% Expected lifetime 2year Physical Characteristics & Applications Weigh 6 Dimension φ~20.4mm, h~16.6mm Storage life 6 months Warranty period 18 months Applications Portable&Fixed gas detector, Gas monitor, Petrochemical, Mine Boiler room, etc.     Hydrogen Sensor (SS1178)   The electrochemical hydrogen gas sensor(SS1178) measures the concentration of H2 with a spontaneous oxidation-reduction reaction. SS1178 has a high selectivity, good reproducibility, small output drift and no power consumption. SS1178 is very suitable for the gas detectors required in the fields such as petrochemical, mine, waste water plant, etc. 　 Operating condition Sensor Hydrogen (SS1178) Temperature range -20~50°C Relative humidity range 15~90% RH Pressure range Atmospheric±10% Performance Detection gas Hydrogen (H2) Detection range 0~1000ppm Output signal 15±10nA/ppm Response time (T90) < 30 sec Typical baseline range 0 to 30ppm Output linearity linearity Repeatability ± 2% Expected lifetime 2year Physical Characteristics & Applications Weigh 6 Dimension ø~20.4mm, h~16.6mm Storage life 6 months Warranty period 24 months Application field Portable & fixed gas detector, Industrial safety(petrochemical, refining) Waste water, Sewage treatment plant, Mine, etc   Certified version using flameproof protection type Exd. Typically used in portable apparatus for hazardous locations. ATEX, IECEx, UL and cUL approved 　 GAS TYPE SENSOR RANGE COMMENTS METHANE 0 - 5% volume Fully characterised for methane. METHANE 0 - 100% volume Fully characterised for methane METHANE 0 - 100% volume High resolution version measures methane from 0 to 100% volume with resolution of 0.01 % for 0-10% methane and 0.1% for 10-100% volume. PROPANE 0 - 2% volume Fully characterised for propane. Cross-reference factors available for: Butane, Pentane, Hexane, Ethanol, Ethylene, Propylene, Ethane, Cyclopentane, Isopropanol, Methanol, Toluene, Acetone, Methyl ethyl ketone (MEK) and Xylene , see Note 1 PROPANE 0 - 100% volume Fully characterised for propane PROPYLENE 0 - 2% volume Fully characterised for propylene BUTANE 0 - 2% volume Fully characterised for butane PENTANE 0 - 2% volume Fully characterised for pentane HEXANE 0 - 1% volume Sensor output linearised for hexane, see Note 1 ETHYLENE 0 - 3% volume Sensor output linearised for ethylene, see Note 1 ETHANE 0 - 3% volume Fully characterised for ethane ETHYLENE OXIDE 0 - 3% volume Fully characterised for ethylene oxide ETHANOL 0 - 5% volume Sensor output linearised for ethanol, see Note 1 METHYL BROMIDE 0 - 25,000 ppm Sensor output linearised for methyl bromide, see Note 1 Note 1: Temperature performance may vary from the specifications on the hydrocarbon sensor data sheets. Refer to data sheet TDS0050 on the Dynament website for further information.   Certified version using flameproof protection type Exd. Typically used in portable apparatus for hazardous locations. ATEX, IECEx, UL and cUL approved 　 PREMIER CARBON DIOXIDE SENSORS GAS TYPE SENSOR RANGE RESOLUTION CARBON DIOXIDE 0 - 500 ppm 10 ppm from 0 to 250 ppm, then 20 ppm up to FSD CARBON DIOXIDE 0 - 1000 ppm 20 ppm from 0 to 500 ppm, then 40 ppm up to FSD CARBON DIOXIDE 0 - 2000 ppm 50 ppm from 0 to 1000 ppm, then 100 ppm up to FSD CARBON DIOXIDE 0 - 5000 ppm 50 ppm from 0 to 2500 ppm, then 100 ppm up to FSD CARBON DIOXIDE 0 - 10,000 ppm 100 ppm from 0 to 5000 ppm, then 200 ppm up to CARBON DIOXIDE 0 - 2% volume 0.025% vol from 0 to 1% vol, then 0.05% vol up to FSD CARBON DIOXIDE 0 - 5% volume 0.025% vol from 0 to 2.5% vol, then 0.05% vol up to FSD CARBON DIOXIDE 0 - 100% volume 0.5% vol from 0 to 50% vol, then 1% vol up to FSD Gas Type Detecting Range Sampling Method Permissible Standards LEL(%Vol) Specific Gravify O₂ 0 - 30% Electrochemical 19.5% ~ 23.5% - 1.11 CO 0 -1,000ppm Electrochemical 25ppm 12.5 0.968 H₂S 0 - 500ppm Electrochemical 10ppm 4.3 1.19 SO₂ 0 - 20ppm Electrochemical 2ppm - 2.26 H₂ 0 - 1,000ppm Electrochemical - 4% vol 0.07 NH₃ 0 - 50ppm Electrochemical 25ppm 15 0.6 CI₂ 0 - 100ppm Electrochemical 1ppm - 2.49 HCI 0 - 30ppm Electrochemical 5ppm - 1.27 HCN 0 - 100ppm Electrochemical 10ppm 5.6 0.941 O₃ 0 - 2ppm Electrochemical 0.1ppm - 1.65 NO 0 - 1,000ppm Electrochemical 25ppm - 1.53 NO₂ 0 - 150ppm Electrochemical 3ppm - 1.58 PH₃ 0 - 20ppm Electrochemical 0.3ppm 1 1.18 SiH₄ 0 - 50ppm Electrochemical 5ppm 13.5 1.11 CO₂ 0 - 15,000ppm NDIR 5000ppm - 1.5 0 - 500ppm up to 0 - 5% Vol IR Hydrocarbons 0 - 100% Vol IR - - - C₄H10 0 - 2% Vol IR - 1.86 2.00 C₂H6 0 - 3% Vol IR - 3.00 1.00 CH₃CH₂OH 0 - 5% Vol IR - 3.60 1.60 C₂H₄ 0 - 3% Vol IR - 2.75 1.00 C₂H₄O 0 - 3% Vol IR - 3.00 1.50 CH₃(CH₂)₄CH₃ 0 - 1% Vol IR - 1.20 3.50 CH₄ 0 - 5% or 0 - 100% Vol IR - 5.00 0.55 C-H₃Br 0 - 25,000ppm IR - 10.00 3.30 N₂O 0 - 1000ppm up to 0-1% Vol IR 50ppm - 1.53 C5H12 0 - 2% Vol IR - 1.5 2.5 CH₃CH₂CH₃ 0 - 2% Vol IR - 2.20 1.50     SPECIFICATION Sensor Type Electrochemical, Catalytic, IR sensor (Oxygen, Carbon monoxide, Hydrogen Sulfide, Hydrogen, Ammonia, Sulfur Dioxide, Nitrogen Dioxide, Nitric Oxide, Combustible (CH4) ) Dimensions Main board : 67 mm x 27 mm x 36 mm Small sensor board : 21 mm x 27 mm Input Voltage Analog 10-30 V DC or Digital 5 V DC Analog Signal Outputs 4-20mA Digital Signal Outputs TTL ( 3V Level ) TTL Parameter Baud rate : 9600 bps, Parity : none, Stop bit : 1, Data bit : 8 Calibration Switch O2 : ZERO Calibration 10 sec, SPAN Calibration 3-8 sec More Type : ZERO Calibration 3-8 sec, SPAN Calibration 10 sec           SPECIFICATION Target Gases Odorous gases such as ammonia and H2S, volatile organic compounds (VOC), hydro carbons (HC) and ethanol CO2 Detecting Method Metal oxide semiconductor Non Dispersive Infrared (NDIR) Input Voltage 5 to 12VDC Signal Outputs RS 232 / RS 485 Applications Air cleaners, Ventilation control, Air quality monitors, VOC monitors, Odor monitors CO2 monitor 日本Figaro气体传感器选型  日本NEMOTO气体传感器  日本FIS气体传感器  英国CITY城市气体   CITY公司/IT公司/SENSORIC公司气体传感器选购指南  英国Alphasense气体传感器选型  瑞士Membrapor气体传感器选型  德国IT公司气体传感器选购资料  德国SENSORIC公司气体传感器  RAE气体传感器气体检测仪  意大利森斯特传感器  Dittrich气体产品  国产气体传感器选型  DCS公司红外产品 VTI公司红外产品 SENSORS公司红外热导产品 爱丁堡公司红外产品Honeywell传感器  SHINYEI传感器  E2V传感器 GE传感器SMARTGAS传感器MSI传感器MEAS传感器 英国SSC气体检测 宝亚呼吸防护设备 Dynament气体传感器德国Schutz NDIR 红外气体传感器美国MAXTEC产品  美国Teledyne气体分析仪及氧传感器  美国AMI氧分析仪及传感器  美国AII氧分析仪传感器 Sensors Direct 加拿大BW科技日本新宇宙NEW COSMOSSERVOMEX气体分析英国GSS气体传感器英国SST传感器 southland sensing EnviteC安维特 韩国SYHITECH 韩国SENKO 韩国SOHA 韩国KNC(NEWCERA) 韩国KOREA DIGITAL  韩国ELT SUNSTAR气体传感器 　 电化学气体传感器 半导体气体传感器 催化燃烧式气体传感器 固体电解质气体传感器 热传导式气体传感器 红外气体传感器 离子烟雾传感器 机动车用气体传感器 气体变送器/检测仪 O2氧气传感器专场 CO2二氧化碳传感器专场 CH4甲烷传感器专场粉尘传感器/灰尘传感 室内空气质量监测控制 温湿度监测控制 医疗设备用传感器   红外气体分析元件1 红外气体分析元件2 红外气体分析元件3  激光红外气体分析元件1 激光红外气体分析元件2 激光红外气体分析元件3 气体变送器模块 BW便携式气体检测仪 BW固定式气体检测仪CO传感器 S02传感器H2S传感器 NH3传感器 NO传感器 NO2传感器 CH2O传感器 CL2传感器 HCL传感器 H2传感器O3传感器C2CL4传感器C2H4传感器 HF传感器 HBR传感器 COCL2传感器 HCN传感器 ASCL3传感器 ASF3传感器C4H6传感器 CLO2传感器 SIH2CL2传感器 （CH3传感器NH传感器 GeCL4传感器 I2传感器 PCL3传感器 SICL4传感器 SO2F2传感器 酒精传感器其它
