CMOS Image Sensor - Analog

　

 OV5116

 OV6910  OV7411

 OV7910

 OV7430

 OV7930

 OV7940 OV7950
 Color  Mono Color Mono  Color Mono  Color Color Color

 Lens Format

 1/4"

 1/4"

 1/3"

 1/4"

 1/3 1/3"

 Scanning

 Interlace

 Interlace

 Interlace　

 Interlace

 Interlace Interlace

 Video Output

 1 Vp-p composite video

 1 Vp-p composite video

 Composite Video: PAL/NTSC or S_Video

 Component video: RGB/YUV

 NTSC

 Composite Video: PAL/NTSC NTSC

 Picture Element

 H320xV240 (EIA)

 H352 x V288 (CCIR)

　H366xV288(CCIR)

H306xV240(EIA)

 H628 xV582 (PAL)

 H510 x V492(NTSC)

 H510 x V492

 H628xV586 H656xV492

 Effective Image Area

 3.2 x 2.5mm

 　2.85x2.16

 5.78 x 4.19mm(PAL)

 4.69 x 3.54mm(NTSC)

  4.0 x 3.08mm 5.961x4.276mm 4.08x3.102
 Package  28p LCC 　28p LCC  48p LCC

 28p LCC

 48p LCC 48p LCC

CMOS Image Sensor - Digital
　 Lens Format Array Size Pixel Size(um) Image Area(mm) Operation Voltage(V) Data Output Package
OV6620 1/4 352x288 9x8.2 3.1x2.5 5/3.3 RAW/YUV 48p LCC
OV6630 1/4 352x288 9x8.2 3.1x2.5 3.3 RAW/YUV 48p LCC
OV6650 1/7 352x288 5.6x5.6 1.97x1.61 2.5 RAW/YUV CSP-22
OV7620 1/3 640x480 7.6x7.6 4.86x3.64 5 RAW/YUV 48p LCC
OV7649 1/4 640x480 5.6x5.6 3.6x2.7 2.5 RAW/YUV CSP-22
OV7660 1/5 640x480 4.2x4.2 2.76x2.05 2.5/1.8 RAW/YUV CSP-22
OV9620 1/2 1280x1024 5.2x5.2 6.66x5.32 3.3/2.5 RGB 10bit Raw 48p LCC
OV9650 1/4 1300x1028 3.18x3.18 4.13x3.28 3.3/1.8 RAW/YUV CSP-28
OV3620 1/2 2048x1538 3.18x3.18 6.59x4.9 3.3/1.8 RGB 10bit Raw 48p LCC
OV5610 1/1.8

2592x1944

 2.8x2.8 7.33x5.44 3.3/1.8 RGB 10bit Raw 48p LCC
OV5620 1/2.5

2592x1944

 2.8x2.8 7.33x5.44 3.3/1.8 RGB 10bit Raw 48p LCC
The CameraChip Family

    OmniVision's family of CMOS CameraChips enable a wide range of low cost, high quality digital and     analog camera designs for mass market imaging applications.
    Anecessary attachment for any CameraChip datasheet: The Serial Camera Control Bus Functional     Specifications

    About OmniVision’s Lead-Free Products


OmniVision’s sensors with the CLCC package are non-Pb. CSP and BGA packages are also available non-Pb.
   OmniVision’s RoHS Compliance



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV5610-C03A
　
OV5620-C03A
　		 1/2.5" 7.5-120 fbs Raw RGB data 48-pin CLCC
OV5620-C00A Color QSXGA,SXGA VGA,HF,D1 1/2.5" 7.5-120 fbs Raw RGB data COB(no backgrinding)
OV5623-G00A Color QSXGA 1/2.5" 7.5-120 fbs Raw RGB data COB(no backgrinding)
OV5630-V58A Color QSXGA,VGA QVGA, 1080p 720p 1/3.2'' 15-60fbs Raw RGB data 58-pin CSP2
OV5630-VL9A Color QSXGA, VGA QVGA, 1080p 720p 1/3.2'' 15-60fbs Raw RGB data 58-pin CSP2
OV5633-C48A Color QSXGA, VGA QVGA, 1080p 720p 1/3.2'' 15-60fbs Raw RGB data 48-pin CLCC
OV5633-C00A Color QSXGA, VGA QVGA, 1080p 720p 1/3.2'' 15-60fbs Raw RGB data 48-pin CLCC



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV3630-VL5A Color QXGA,XGA,HF
　		 1/3" 15fbs full res Raw RGB data 36-pinCSP2
OV3630-G00A Color QXGA,XGA,HF 1/3" 15fbs full res Raw RGB data COB(no backgrinding)
OV3632-VL5A Color QXGA,XGA,HF 1/3" 15fbs full res Raw RGB data 36-pinCSP2
OV3640-VL9A Color QXGA,XGA,and below 1/4" 15fbs full res Raw RGB data 56-pinCSP2
OV3640-G00A Color QXGA,XGA,and below 1/4" 15fbs full res data, RGB COB(no backgrinding)
OV3640-G03A Color QXGA,XGA,and below 1/4" 15fbs full res compressed data,YUV COB (reconstucted wafer)
OV3642-V67A Color QXGA XGA and below 1/4" 15 fps full resolution YUV RGB Raw RGB Data Compressed Data 67-pin CSP2
OV3642-VL9A Color QXGA XGA and below 1/4" 15 fps full resolution YUV RGB Raw RGB Data Compressed Data 67-pin CSP2
OV3647-V47A Color QXGA XGA HF 1/4" 15 fps full resolution Raw RGB Data 47-pin CSP2
OV3647-VL9A Color QXGA XGA HF 1/4" 15 fps full resolution Raw RGB Data 47-pin CSP2



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV2640-VL9A Color UXGA,SVGA and below 1/4" 15fbs full res Raw RGB data ,RGB compressed data,YUV 38-pinCSP2
OV2640-G00A Color UXGA,SVGA and below 1/4" 15fbs full res Raw RGB data ,RGB compressed data,YUV COB(no backgrinding)
OV2640-G03A Color UXGA,SVGA and below 1/4" 15fbs full res Raw RGB data ,RGB compressed data,YUV COB (reconstucted wafer)
OV2650-VL9A Color UXGA,SVGA and below 1/5" 15fbs full res Raw RGB RGB data, YUV 38-pinCSP2
OV2650-G00A Color UXGA,SVGA and below 1/5" 15fbs full res Raw RGB RGB data, YUV COB(no backgrinding)
OV2650-G03A Color UXGA,SVGA and below 1/5" 15fbs full res Raw RGB RGB data, YUV COB (reconstucted wafer)



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV9653-VL1A Color SXGA,VGA, QVGA, CIF, QCIF, QQVGA, QQCIF 1/4" 15-60fbs YUV ,RGB, Raw RGB data 28-pinCSP2
OV9653-G03A Color SXGA,VGA, QVGA, CIF, QCIF, QQVGA, QQCIF 1/4" 120fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV9655-VL1A Color SXGA,VGA,   and below 1/4" 15-30fbs YUV ,RGB, Raw RGB data 28-pinCSP2
OV9655-G00A Color SXGA,VGA,    and below 1/4" 15-30fbs YUV ,RGB, Raw RGB data COB(no backgrinding)
OV9655-G03A Color SXGA,VGA,   and below 1/4" 15-30fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV9656-VL1A Color SXGA,VGA,CIF and below 1/4" 15-30fbs YUV ,RGB, Raw RGB data 28-pin CSP2
OV9660-VL9A Color SXGA,VGA, QVGA CIF       and below 1/5" 15-60fbs YUV ,RGB, Raw RGB data 26-pin CSP2
OV9660-G03A Color SXGA,VGA, QVGA CIF       and below 1/5" 15-60fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV9665-V26A Color SXGA VGA QVGA CIF and below 1/5" 15-60fbs YUV RGB Raw RGB Data 26-pin CSP2
OV9665-VL9A Color SXGA VGA QVGA CIF and below 1/5" 15-60fbs YUV RGB Raw RGB Data 26-pin CSP2
OV9710-V28A Color WXGA 640 x 400 1/4" 30-60fbs Raw RGB Data 28-pin CSP2
OV9710-VL1A Color WXGA 640 x 400 1/4" 30-60fbs Raw RGB Data 28-pin CSP2



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV7141-C01A B/W VGA,QVGA
　		 1/4" 30-60fbs YUV ,RGB, Raw RGB data 28-pin CLCC
OV7141-P01A B/W VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 28-pin PLCC
OV7148-KL6A B/W VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7161-G00A B/W VGA,QVGA, QQVGA,CIF QCIF,QQCIF 1/5" 30-60fbs
　		 YUV ,RGB, Raw RGB data COB(no backgrinding)
OV7161-KL6A B/W VGA,QVGA, QQVGA,CIF QCIF,QQCIF 1/5" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7211-C00A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB 48-pin PLCC
OV7211-F00V Color VGA
　		 1/4" 30-60fbs YUV ,RGB 48-pin QFP
OV7221-C01A Color VGA,QVGA,CIF and below
　		 1/4" 60 fbs for VGA YUV ,RGB 28-pin CLCC
OV7221-VL1A Color VGA,QVGA,CIF and below 1/4" 60 fbs for VGA YUV ,RGB 28-pin CSP2
OV7620 Color VGA,QVGA 1/3" 30fbs YUV,GRB,RGB raw data 48-pin CLCC
OV7640-C01A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 28-pin PLCC
OV7640-P01A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 28-pin PLCC
OV7648-KL6A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7649-KL6A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7650-KL6A Color VGA,QVGA, CIF,QCIF 1/4" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7660-KL6A Color VGA,QVGA, QQVGA,CIF, QCIF,QQCIF 1/5" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP
OV7660-G00A Color VGA,QVGA, QQVGA,CIF, QCIF,QQCIF 1/5" 30-60fbs YUV ,RGB, Raw RGB data COB(no backgrinding)
OV7663-VL6A Color VGA,QVGA, QQVGA,CIF, QCIF,QQCIF 1/5" 30-60fbs YUV ,RGB, Raw RGB data 22-pin CSP2
OV7663-G03A Color VGA,QVGA, QQVGA,CIF, QCIF,QQCIF 1/5" 30-60fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV7668-G00A Color VGA sub-sampling mode 1/5" 30-60fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV7670-VL2A Color VGA,CIF          and below 1/6" 30 fbs YUV ,RGB, Raw RGB data 24-pin CSP2
OV7670-G00A Color VGA,CIF          and below 1/6" 30 fbs YUV ,RGB, Raw RGB data COB(no backgrinding)
OV7670-G03A Color VGA,CIF          and below 1/6" 30 fbs YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV7680-VL2A Color VGA 1/10" 30 fbs for VGA YUV ,RGB, Raw RGB data 24-pin CSP2
OV7680-G00A Color VGA 1/10" 30 fbs for VGA YUV ,RGB, Raw RGB data COB (no backgrinding)
OV7680-G03A Color VGA 1/10" 30 fbs for VGA YUV ,RGB, Raw RGB data COB (reconstucted wafer)
OV7710-C00A Color VGA,QVGA 1/4" 30-60fbs YUV ,RGB 48-pin CLCC
OV7710-F00V Color VGA 1/4" 30-60fbs YUV ,RGB 48-pin QFP
OV7720-C01A Color VGA,QVGA,CIF and below 1/4" 60 fbs YUV ,RGB 28-pin CLCC
OV7720-VL1A Color VGA,QVGA,CIF and below 1/4" 60 fbs YUV ,RGB 28-pin CSP2
OV7725-VL1A Color VGA,QVGA,CIF and below 1/4" 60 fbs for VGA YUV ,RGB 28-pin CSP2
OV7725-G00A Color VGA,QVGA,CIF and below 1/4" 60 fbs for VGA YUV ,RGB COB (no backgrinding)
OV10121-C00A Color WVGA,VGA, QVGA 1/3" to 1/4" 30-60fbs HDR YUV, Raw RGB 48-pin CLCC
OV10121-Q00A Color WVGA 1/3" to 1/4" 30-60fbs HDR YUV, Raw RGB 48-pin QFP
OV10620-C00A Color WVGA,VGA, QVGA 1/3" to 1/4" 30-60fbs HDR YUV, Raw RGB 48-pin CLCC
OV10620-Q00V Color WVGA 1/3" to 1/4" 30-60fbs HDR YUV, Raw RGB 48-pin QFP
OV7690-A20A Color VGA QVGA 1/13" 30 fps for VGA YUV RGB Raw RGB Data 20-pin CSP3
OV7690-AL9A Color VGA QVGA 1/13" 30 fps for VGA YUV RGB Raw RGB Data 20-pin CSP3



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV5116-C11A B/W
320 x 240		 1/4" 60fieids/sec NTSC 28-pin LCC
OV5116-C21A B/W
352 x 288		 1/4" 50fieids/sec PAL 28-pin LCC
OV6920-VL9A Color 320 x 240 1/18" 60fieids/sec NTSC 9-pin CSP2
OV7411 B/W
N: 510 x 492 P:628 x 586 		1/3" 60fieids/sec NTSC,PAL 48-pin CLCC
OV7451-C10A B/W 656 x 492 1/4" 60fieids/sec NTSC 48-pin CLCC
OV7451-F10A B/W 656 x 492 1/4" 60fieids/sec NTSC 48-pin QFP
OV7910 Color
N: 510 x 492 P:628 x 586 		1/3" 60fieids/sec NTSC,PAL 48-pin CLCC
OV7930 Color
510 x 492		 1/4" 60fieids/sec NTSC COB (no backgrinding)
OV7949-C10A Color 510 x 496 1/3" 60fieids/sec NTSC 48-pin CLCC
OV7949-C20A Color
628 x 586		 1/3" 50fieids/sec PAL 48-pin CLCC
OV7949-Q10V Color 510 x 496 1/3" 60fieids/sec NTSC 48-pin QFP
OV7949-Q20V Color 628 x 586 1/3" 60fieids/sec PAL 48-pin QFP
OV7950-C10A Color 656 x 492 1/4" 60fieids/sec NTSC 48-pin CLCC
OV7950-F10V Color 656 x 492 1/4" 60fieids/sec NTSC 48-pin QFP



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV6620 Color CIF,QCIF 1/4" 60fbs YUV,GRB,RGB raw data 48-pin CLCC
OV6630 Color CIF,QCIF 1/4" 60fbs YUV,GRB,RGB raw data 48-pin CLCC
OV6680-VL9A Color SGV
　		 1/9" 30 fbs at full resolution YUV ,RGB, Raw RGB data 23-pin CSP2



Part Number Color Resolution Optixal format Format rate Output Format Package options
OV6130-C00A B/W CIF,QCIF
　		 1/4" Up to 60 fps   48-pin CLCC

OV518
OV519
OV511+
　
　

　

　
　
型号　
品牌
D/C
封装
备注

OV7620
  OV    镜面CLCC
   CCD图象传感器
OV7120
  OV    镜面CLCC
   CCD图象传感器
OV8610
  OV   镜面

OV9620
  OV    CLCC

OV7635
  OV    CLCC

FXC05115
  OV   CLCC

OV5116
  OV   CLCC
   CCD图象传感器
OV7910
  OV   CLCC
   CCD图象传感器
OV7610
  OV   CLCC
   CCD图象传感器
OV3620
  OV   CLCC
   CCD图象传感器
OV3610
  OV   CLCC
   CCD图象传感器
OV2610
  OV   CLCC
   CCD图象传感器
